SL203 70W



PRODUCT INSTRODUCTION



MAIN SPECIFICATIONS (T=25℃)

NUMBER

ITEM

DESCRIPTION

01

Input Voltage

AC85-264V 47-63Hz

02

LED

48 PCS (Bridgelux Lumileds)

03

System Power

70W

04

LED Efficiency

90-100Lm/W

05

Initial Flux

>7000Lm (Cool White)

>6700Lm (Natural White)

>6300Lm (warm white)

06

Power Factor

>0.9

07

Color

Warm White /Natural White/Cool White

08

CRI

Ra>80

09

Color Temperature

2700-3300K (Warm White)

4000-5000K (Natural White)

5300-7000K (Cool White)

10

Center Illuminance

3.0M196 Lux

6.0M39 Lux

9.0M17 Lux

11

Beam Angle

120°

12

Life Span

>50,000 Hours

13

Operating Temperature

-25 to +55

14

Storage Temperature

-40 to +65

15

Connect Wire

Brown  L                   Black  L

Blue   N            OR    White  N

Yellow/Green  GND         Green GND

16

Certifications

CE, RoHS

17

Net Weight

5.4Kg

18

Size

495x292x98mm (61mm)

19

Light IP Rating

IP66
